Room Type Humidity Transmitter Pt100
Humidity_Room Type Humidity Transmitter Pt100

Product Code: RMT.HT.1021.Pt100
For more information about the product;

Room Type Humidity Transmitter Pt100

RMT.HT.1021 Room Type Humidity and Temperature Transmitters are the humidity and temperature sensing elements designed to give the humidity and temperature values (0 ... 100% RH) of the environment as 0-10V, 4-20mA signal output by mounting the humidity sensor to the room. RMT.HT.1021 Room Type Humidity and Temperature Transmitters are used in many applications such as air handling units where humidity and temperature are monitored or controlled, hygienic air conditioner, pool dehumidifier, greenhouses, storage areas, laboratories and data centers.

Technical Specification

Environmental Features
Operation Temperature0... +50°C
Storage Temperature-25... +70°C
Protect ClassIP20
Packet
Mounting MethodRoom
DimensionL100xW90xH30 mm
Weight115 gr
Electrical Spesification
Control
Relay Current Capacity
Heat Range
Supply24VAC/DC ±10%
OutputsAO1: 0-10V <> 0 … 100% r.h. / . AO2: 0-10V <> 0 … 100 °C
Power ConsumptionMax 2VA
ConnectionTerminal Connector 1.5 mm2
