Wall Mounted CO2 Sensor
CO2_Wall Mounted CO2 Sensor CO2_Wall Mounted CO2 Sensor

Product Code: WMT.CT.1021
For more information about the product;

Wall Mounted CO2 Sensor

Havkon WMT.CT series wall mounted CO₂ transmitters are designed for accurate and reliable carbon dioxide (CO₂) measurement in HVAC air streams and internal unit installations. Using long-life NDIR sensing technology, the device ensures stable and drift-resistant CO₂ monitoring for ventilation control and indoor air quality applications. The compact IP54 enclosure combined with an external sensor probe allows precise measurement directly within internal airflow. Selectable analog outputs (0–10V / 2–10V / 4–20mA) provide seamless integration into building automation systems

Technical Specification

Environmental Features
Operation Temperature0... +50°C
Storage Temperature-25... +70°C
Protect ClassIP54
Packet
Mounting MethodWall mounting with screws
DimensionL100xW80xH40 mm
Weight168 gr
Electrical Spesification
Control
Relay Current Capacity
Heat Range
Supply24VAC/DC ±10%
OutputsAO1: 0-10V <> 0 … 2000ppm
Power ConsumptionMax. 3VA
ConnectionTerminal Connector 1.5 mm2
